Sanyo SC-15(M) - Manual (Page 4)

- 4 -
For Parts or Service Contact
SANYO FISHER SERVICE CORPORATION.
21605 Plummer Street,
Chatsworth, CA 91311
Parts List NOTE : The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-15(M) (U.S.A.)
Sep./’99/1,000 Printed in Japan
Key
No.
Key
No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:G-328(GREEN),NN-B(BLACK)
1 649 000 3125 DUST COVER (G-328) 1 51 649 000 3347 HOSE ASSEMBLY (L=750) 1
2 411 006 8301 SCR TPG PAN 4X20 6 52 649 000 3354 HOSE HOLDER (NN-B) 1
3 649 000 3132 HANDLE (NN-B) 1 53 649 000 3361 ROTARY BEND SET RING (G-328) 1
A 4 649 000 3149 SWITCH 1 54 649 000 3378 GRIP (NN-B) 1
5 649 000 3156 CASE UPPER (G-328) 1 55 649 000 3385 EXTENSION PIPE ASSEMBLY B KEYNO.56-58 1
A 6 649 000 3163 CORD ASSEMBLY (BLACK) L=300
1 56 649 000 3392 PIPE SET RING (G-328) 1
7 649 000 2586 SUB-FILTER 1 57 649 000 3408 EXTENSION PIPE B (NN-B) 1
8 649 000 0520 WIRE CONNECTOR (CE-230) 3 58 649 000 3415 CORD STORAGE HOOK (NN-B) 1
9 649 000 2654 SCREW 4X16 1 59 649 000 3422 CREVICE TOOL (NN-B) 1
A 10 649 000 3170 POWER CORD (UL)
1 60 649 000 3439 EXTENSION PIPE ASSEMBLY A KEYNO.61-65 1
11 649 000 3187 PAPER BAG (SC-P11) 1 61 649 000 3392 PIPE SET RING (G-328) 1
12 649 000 3194 DUST BOX PACKING 1 62 649 000 3446 PIPE COVER (NN-B) 1
13 649 000 3200 FRONT COVER (NN-B) 1 63 649 000 3453 BUTTON (PIPE) (G-328) 1
14 649 000 3217 AIR INLET PACKING (NN-B) 1 64 649 000 3460 CLAMP SPRING 1
15 649 000 3811 CAUTION LABEL 1 65 649 000 3477 EXTENSION PIPE A (NN-B) 1
16 649 000 3224 ELECTROSTATIC MICRON FILTER 1 66 649 000 3484 FLOOR NOZZLE COMP. KEYNO.67-77 1
17 649 000 3231 MOTOR CUSHION FRONT 1 67 649 000 3491 FLOOR NOZZLE CASE (G-328) 1
A 18 649 000 3248 MOTOR COMP. (AC 120V) 1 68 649 000 3392 PIPE SET RING (G-328) 1
A 649 000 3255 CARBON BRUSH ASSEMBLY
2 69 649 000 3507 ROTARY BEND (NN-B) 1
19 649 000 3262 LEAD WIRE (RED) L=250 1 70 649 000 3514 BEND SET PIECE (NN-B) 2
A 20 649 000 3279 CORD ASSEMBLY (BLACK) L=350 1 71 649 000 3521 ROTARY PIPE (NN-B) 1
21 649 000 3286 SILENCER PIPE 1 72 649 000 3538 FLOOR NOZZLE ROLLER (NN-B) 2
22 649 000 3293 MOTOR CUSHION REAR 1 73 649 000 3545 FLOOR NOZZLE BASE (NN-B) 1
23 649 000 3309 OUTLET FILTER 2 74 649 000 3552 SHAFT FRONT 2
A 24 649 000 1800 CORD ASSEMBLY (BLACK) L=200 2 75 649 000 4733 WHEEL SMALL ASSEMBLY (NN-B) 2
A 25 649 000 3606 FUSE ASSEMBLY (10A 120 )
1 76 411 007 0700 SCR TPG TRS 4X16 4
26 649 000 3316 CASE LOWER (NN-B) 1 77 649 000 3576 BRUSH BASE ASSEMBLY 1
27 649 000 6010 NAME PLATE 1
28 649 000 3330 INDICATOR FILTER 1
