Removing the roof
Guidelines for Rescue Services, smart, 2006 Page 23
Rescue
• Cut through the C pillars below the gas filled
spring struts of the folding rear window.
P63.00 2053 00
smart forfour (model 454): Folding back the roof
• Cut through the A pillars
• Saw out the windshield at the A pillars and
above the instrument panel. The upper side
(roof side) of the windshield remains intact. It
remains attached to the weather stripping, and
is removed along with the roof itself once the
A, B and C pillars have been cut.
P62.00 2088 00
• Cut through the B pillars below the seat belt
height adjustment mechanism
P65.00 2107 00
i When the C pillars are cut, the frameless
single pane safety glass rear window will
probably break.
