Pushing away the instrument panel
Page 20 Guidelines for Rescue Services, smart, 2006
Rescue
• Make a relief cut at the bottom of the A pillar
P62.00 2089 00
• Position a rescue ram in the area of the joint
(arrow) between the instrument panel
crossmember and the A pillar.
P62.00 2090 00
• Position the rescue ram on the B pillar. To
prevent the base of the rescue ram from
breaking through, make sure that the
supporting points are strong. The rocker
panel attachments (1) available with the rescue
ram are particularly well suited for stabilizing
purposes.
• Extend the rescue ram as far as necessary
• To prevent vehicle parts from springing back,
the rescue ram should be left under pressure
until the casualty or casualties have been
rescued from the vehicle.
P62.00 2091 00
i Due to its construction, the A pillar is not
strong enough to allow the use of a rescue ram.
The ram deforms the A pillar and fender without
pushing the instrument panel forward out of
the way.
