Parking brake group - upper – Simplicity ZT2348T User Manual
Page 45
39
TP 400-7090-03-CT-D
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
REF NO.
PART NO.
QTY.
DESCRIPTION
Parking Brake Group - Upper
Footnotes:
* - See Electrical Schematic for switch part number
1
3845616
1
BRAKE HANDLE MOUNT
2
3845619
1
BRAKE HANDLE
3
1722302
1
GRIP
4
25011-8
2
CAPSCREW, Hex Hd, 5/16-18 x 1
5
25127
2
NUT, Hex, Serrated Flange, 5/16-18
6
21098
2
BEARING, Flange
7
25013-6
4
CAPSCREW, Hex Hd, 3/8-16 x 3/4
8
25128
6
NUT, Hex, Serrated Flange, 3/8-16
9
3847083
1
BRAKE HANDLE SHAFT
10
25010-14
2
CAPSCREW, Hex Hd, 1/4-20 x 1-3/4
11
25095
2
NUT, Hex, Nylon Lock, 1/4-20
12
3845618
1
BRAKE LINKAGE PIVOT
13
47119
1
BRAKE CONNECTING ROD
14
25035
1
NUT, Hex, 3/8-24
15
25013-16
1
CAPSCREW, Hex Hd, 3/8-16 x 2
16
21171
1
CLEVIS, 3/8-24
17
25034
1
NUT, Hex, 3/8-16
18
25096
1
NUT, Hex, Nylon Lock, 3/8-16
19
25010-6
2
CAPSCREW, Hex Hd, 1/4-20 x 3/4
20
25154
2
WASHER, 1/4
21
3845621
1
SWITCH MOUNT BRACKET
22
*
*
SWITCH (see electrical schematic)
23
25126
2
NUT, Hex, Serrated Flange, 1/4-20
24
25058-14
1
CAPSCREW, Hex Hd, TFL, 3/8-16 x 1-3/4
