17 TP 400-7090-01-CT-D
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
REF NO. PART NO. QTY. DESCRIPTION
Control Cover & Mount Group
Footnotes:
1 3847890 1 CONTROL COVER-RH
2 1719392 1 CUP HOLDER
3 25011-8 18 CAPSCREW, Hex Hd, 5/16-18 x 1
4 25155 18 WASHER, 5/16
5 22308 10 BODY CLIP, 5/16-18
6 3847884 1 CONTROL COVER MOUNT-RH
7 3847893 1 DEBRIS GUARD-RH
8 25127 8 NUT, Hex, Serrated Flange, 5/16-18
9 3847073 2 FAN SHIELD MOUNT
10 25010-8 4 CAPSCREW, Hex Hd, 1/4-20 x 1
11 25154 4 WASHER, 1/4
12 22665 4 BODY CLIP, 1/4-20
13 3846645 2 FAN SHIELD
14 3847891 1 CONTROL COVER-LH
15 21397 2 GROMMET
16 3847885 1 CONTROL COVER MOUNT-LH
17 3847894 1 DEBRIS GUARD-LH
18 3847910 1 CONTROL PANEL PIVOT-LH
19 3847909 1 CONTROL PANEL PIVOT-RH
20 25057 4 NUT, Hex, Nylon Lock, 5/16-18
21 22030 1 FUEL SHUT OFF VALVE
