Installing Batteries (optional)
Your Boom Box can also be used with 8 D-Cell batteries as shown:
1. Push the battery cover latches down and flip up the battery compartment covers to the open position.
2. Insert the 8 D-Cell batteries follow the battery polarity as shown; then close the cover.
Note: The batteries are bypassed automatically whenever the supplied DC Adapter is plugged into the
power jack on the back of the Boom Box.
A
An
ntte
en
nn
na
a A
Aiim
miin
ng
g ffe
ea
attu
urre
e ffo
ou
un
nd
d o
on
n tth
he
e R
Re
ep
plla
ay
y rre
ec
ce
eiiv
ve
err..
The Signal Indicator display screen provides a visual display of the strength of the SIRIUS signal from the
satellite and terrestrial (ground) transmitters. To display the Signal Indicator screen, do the following:
1. Use CHANNEL UP and CHANNEL DOWN buttons to highlight "Signal Indicator" and press the
Select button.
2. Two 10 segment horizontal bar graphs will be displayed with a "-" sign to the left and a "+" sign to the right.
SAT indicates the satellite signal strength while TER indicates the terrestrial signal strength, if a terrestrial
signal is available. To exit the Signal Indicator menu, press the MENU button.
