SUPPLIED COMPONENTS / SUPPLIED HARDWARE
This list identifies the major components you will use to assemble this product.
No. Description Qty.
A1 Treadmill Base 1
A2 Console Assembly 1
735i -301 Right Upright 1
735i -302 Left Upright 1
735i -307 Right Handle Bar 1
735i -308 Left Handle Bar 1
735i -310 Right Protective Cover 1
735i -311 Left Protective Cover 1
Hardware Kit
735i -303 M8x15mm Bolt 14
735i -304 M8 Curve Washer 14
735i -305 M4x15mm Bolt 2
735i -306 M6x15mm Bolt 2
735i -312 M6x65mm Bolt 2
A 5mm Allen Key 1
B 6mm Allen Key 1
735i -209 Safety Key 1
C Silicone Lubricant 1
735i -309 End cap 4
735i -313 M4x10mm Bolt 4
Millimeters
A1
311 310
302 301 A2
308 307
304 306 305 303
B 209 A 312
C 309 313
