9 TP 400-3537-00-AT-SMA
Catcher, Clean Sweep Twin - Adapter & Blade Group
1 1703769 1 TUBE, Transfer
2 1704603 1 LATCH, Tube
3 1960185 1 WASHER, 5/16
4 1935048 1 NUT, Flange Lock, 5/16-18
5 1704341 1 WASHER, Special
6 1919438 3 NUT, ESNA, Hex Lock, 5/16-18
7 1705010 1 ADAPTER, Blade, High Lift
8 1704977 1 BLADE, High Lift, 38” Mower
9 1960371 3 CAPSCREW, Hex Head, 5/16-18 x 3/4
10 1931338 2 CARRIAGE BOLT, 5/16-18 x 1-3/4
11 1931332 1 CARRIAGE BOLT, 5/16-16 x 5/8
12 1703765 1 BAFFLE, 38” Mower
13 1917356 4 LOCKWASHER, 5/16
14 1917372 4 NUT, Hex, 5/16-18
15 1702665 2 SPACER
16 1960273 1 CARRIAGE BOLT, 5/16-18 x 2-1/4
17 1928698 1 NUT, Hex, Centerlock, 5/16-18
18 1679163 1 WING NUT ASSEMBLY
19 1704355 1 BRACKET
20 1703770 1 ADAPTER
21 1960122 1 CAPSCREW, Hex Head, 5/16-18 x 3/4
22 1919326 1 WASHER, 5/16
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1694308 Catcher, Clean Sweep Twin
