Page 53

Chapter 5: Advanced Serverboard Setup
5-19
SMB
A S y s t e m M a n a g e m e n t B u s
header is located at J22. Connect
the appropriate cable here to uti-
lize SMB on your system.
SMB Header
Pin Definitions (J22)
Pin
Number
1
2
3
4
Definition
Data
Ground
Clock
No Connection
SMB Power Connector
Connect the SMB power connec-
tor to J24 (located near the ATX
power connector) to utilize SMB.
SMB PWR
Pin Definitions (J24)
Pin #
1
2
3
4
5
Definition
Clock
Data
N/A
N/A
N/A
