Resound specifications – Samson RS12M User Manual
Page 13
11
RS10
Power Rating (@ 8
Ω):
125 Watts RMS, 220 Watts Peak
Nominal Impedance:
8 Ohms
Frequency Response:
60 Hz – 20 kHz ± 3 dB
Sensitivity:
95 dB SPL @ 1W/1m
MAX SPL:
115dB
LF Driver:
10-inch heavy-duty driver
HF Driver:
1-inch exit, 44mm Mylar diaphragm
compression driver
Protection:
Internal overload Lamp on HF driver
Mounting:
Integral 1 3/8-inch Pole Mount
Receptacle
Weight:
33 lbs. 14.97 kg
RS10M
Power Rating (@ 8
Ω):
125 Watts RMS, 220 Watts Peak
Nominal Impedance:
8 Ohms
Frequency Response:
60 Hz – 20 kHz ± 3 dB
Sensitivity:
95 dB SPL @ 1W/1m
MAX SPL:
115 dB
LF Driver:
10-inch heavy-duty driver
HF Driver:
1-inch exit, 44mm Mylar diaphragm
compression driver
Protection:
Internal overload Lamp on HF driver
Mounting:
25º and 30º wedge monitor position
Weight:
31 lbs. 14.06 kg
RS12M
Power Rating (@ 8
Ω):
175 Watts RMS, 300 Watts Peak
Nominal Impedance
8 Ohms
Frequency Response:
50 Hz – 20 kHz ± 3 dB
Sensitivity:
97 dB SPL @ 1W/1m
MAX SPL:
121dB
LF Driver:
12-inch heavy-duty driver
HF Driver:
1-inch exit, 44mm Mylar diaphragm
compression driver
Protection:
Internal overload Lamp on HF driver
Mounting:
25º and 30º wedge monitor position
Weight:
33 lbs. 14.97 kg
RS15M
Power Rating (@ 8
Ω):
225 Watts RMS, 400 Watts Peak
Nominal Impedance:
8 Ohms
Frequency Response:
40 Hz – 20 kHz ± 3 dB
Sensitivity:
98 dB SPL @ 1W/1m
MAX SPL:
126dB
LF Driver:
15-inch heavy-duty driver
HF Driver:
1-inch exit, 44mm Mylar diaphragm
compression driver
Protection:
Internal overload Lamp on HF driver
Mounting:
30º wedge monitor position
Weight:
42 lbs. 19.05 kg
RESOUND Specifications
