7 TP 400-2616-00-AT-SMA
Tube Group
1 1933896 2 NUT, Hex Nylock, #10-32
2 1960096 6 WASHER
3 1707710 1 ELBOW, Upper, (Broadmoor, 1600, 2600 - Series)
4 1704283 1 ELBOW, Upper, (Conquest, 1700 2700, Prestige, 1800, 2800 - Series)
5 1960404 2 SCREW, Truss Head, #10-32 x 1/2
6 910542 2 RIVET
7 1705063 1 CLIP, Spring
8 1707712 1 TUBE & SPRING ASSEMBLY (Incl. Ref. Nos. 2, 6, & 7)
9 1960252 1 CARRIAGE BOLT, 1/4-20 x 5/8
10 1930641 1 NUT, Hex Flange Lock, 1/4-20
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1694153 Turbo Clean Sweep Twin Catcher
