2-2
SUPER i2DMR-8G2/i2DMR-iG2 User's Manual
IMPORTANT: Always connect the power cord last and always remove it
before adding, removing or changing any hardware components. Make
sure that you install the processor into the CPU socket before you install
the CPU heat sink.
Note: To optimize the functionality and capability of the i2DMR-8G2/
i2DMR-iG2, we recommend that i2DMR-8G2/i2DMR-iG2 be installed in
Supermicro chassis only.
2-2 Itanium2 Processor and Heatsink Installation
When handling the processor package, avoid placing direct
pressure on the label area of the fan. Also, do not place the
motherboard on a conductive surface, which can damage the
BIOS battery and prevent the system from booting up.
!
Locate the following components, which are included in the shipping
package.
A. Locating the components included in the shipping package
Two (2) Power Pod (VRM-0008)
Two (2 )Itanium 2 Heatsinks (SNK-0046)(*not included; sold separately)
One Package of Retention Mechanism, including:
One (1) Retention Mechanism (SKT-0147-RM-IT2)
Six (6) 6-32 8mm Screws
Eight (8) M3 5mm Screws
Three (3) 6-32 4.5mm Screws
Warning: The heatsink on the MRH-D chip has been pre-installed by the
manufacturer. Please do not touch it. Turning the heatsink in a wrong
way will damage it and will void the manufacturer's warranty.
One (1) M2.5 Hex Key (*for CPU removal and locking)
