Simplicity ZT2761F - Manual (Page 51)

45 TP 400-7087-02-SL-D
The above parts group applies to the following Model Nos.:
ZT2561F
ZT2761F
REF NO. PART NO. QTY. DESCRIPTION
Wheels & Tires Group
Footnotes:
1 22631S 2 WHEEL & TIRE ASSEMBLY, Front, 13 x 5.0 x 6, Complete (includes Ref 2 - 5)
2 22029-1 2 TIRE, Front, 13 x 5.0 x 6
3 22631S-1 2 WHEEL ASSEMBLY, Front, for 13 x 5.0 x 6 Tires, Complete (includes Ref 6 & 7)
4 22631S-2 4 BEARING, Taper Roller (2 per tire)
5 22631S-3 4 GREASE SEAL (2 per tire)
6 47103 4 ADAPTER, Caster Wheel (2 per tire)
7 25017-60 2 CAPSCREW, Hex Hd, 1-2/13 x 7-1/2
8 25056 2 NUT, Hex, Nylon Lock, 1-2/13
9A 22396S 2 WHEEL & TIRE ASSEMBLY, Rear, 23 x 10.5 x 12, Complete (Includes Ref 10A & 11A)
(ZT2561F - S/N: 877 & below)
(ZT2761F - S/N: 937 & below)
9B 23243 2 WHEEL & TIRE ASSEMBLY, Rear, 23 x 10.5 x 12, Complete (Includes Ref 10A & 11A)
(ZT2561F - S/N: 878 & above)
(ZT2761F - S/N: 938 & above)
10A 22396-1 2 TIRE, Rear, 23 x 10.5 x 12
(ZT2561F - S/N: 877 & below)
(ZT2761F - S/N: 937 & below)
10B 23243-1 2 TIRE, Rear, 23 x 10.5 x 12
(ZT2561F - S/N: 878 & above)
(ZT2761F - S/N: 938 & above)
11A 22898-2 2 WHEEL ASSEMBLY, Rear, 12 x 8.5
(ZT2561F - S/N: 877 & below)
(ZT2761F - S/N: 937 & below)
11B 22396S-2 2 WHEEL ASSEMBLY, Rear, 21 x 8.5
(ZT2561F - S/N: 878 & above)
(ZT2761F - S/N: 938 & above)
12 22215 10 WHEEL LUG, 1/2 x 1-5/8
