Simplicity ZT2761F - Manual (Page 45)

39 TP 400-7087-02-SL-D
The above parts group applies to the following Model Nos.:
ZT2561F
ZT2761F
REF NO. PART NO. QTY. DESCRIPTION
Parking Brake Group-Upper
Footnotes:
* - See Electrical Schematic for switch part number
1 1722302 1 GRIP
2 3845619 1 BRAKE HANDLE
3 25095 2 NUT, Hex, Nylon Lock, 1/4-20
4 25011-8 2 CAPSCREW, Hex Hd, 5/16-18 x 1
5 25127 2 NUT, Hex, Serrated Flange, 5/16-18
6 3845616 1 BRAKE HANDLE MOUNT
7 25010-14 2 CAPSCREW, Hex Hd, 1/4-20 x 1-3/4
8 25128 6 NUT, Hex, Serrated Flange, 3/8-16
9 25013-6 4 CAPSCREW, Hex Hd, 3/8-16 x 3/4
10 21098 2 BEARING, Flange
11 3845610 1 BRAKE HANDLE SHAFT
12 3845618 1 BRAKE LINKAGE PIVOT
13 25010-6 2 CAPSCREW, Hex Hd, 1/4-20 x 3/4
14 25154 2 WASHER, 1/4
15 25058-14 1 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4 TFL
16 3845621 1 SWITCH MOUNT BRACKET
17 25126 2 NUT, Hex, Serrated Flange, 1/4-20
18 * * SWITCH (see electrical schematic)
