Other Information
115
O
th
e
r In
fo
rm
at
io
n
Specifications
Projection System 3 LCD Panels, 1 lens projection system
LCD Panel 0.87 inch TFT LCD panel Approx. 3.28 million dots (1,042,168 pixels)
Projection Lens High Performance, large diameter hybrid lens F2.4
Antenna 75 ohm external terminal for VHF/UHF
Lamp UHP lamp, 120W
XL-2100U
Television System NTSC, American TV Standard
Screen Size (measured diagonally) KDF-60XBR950: 60 inches
KDF-70XBR950: 70 inches
Channel Coverage
VHF 2-13
UHF 14-69
DTV 1-999
CATV 1-125
Power Requirements 120V, 60 Hz
Number of Inputs/Outputs
DVI-HDTV 1 terminal, 3.3 V T.M.D.S., 50 ohms
The DVI-HDTV input terminal is compliant with the EIA-861 standard and is
not intended for use with personal computers.
Video (IN) 4 1 Vp-p, 75 ohms unbalanced, sync negative
S Video (IN) 4 Y: 1 Vp-p, 75 ohms unbalanced, sync
negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Audio (IN) 6 500 mVrms (100% modulation)
Impedance: 47 kiloohms
AUDIO (VAR/FIX) OUT 1 500 mVrms at the maximum volume setting
(Variable)
500 mVrms (Fixed)
Impedance (output): 2 kiloohms
CONTROL S (IN) 1 minijack
CONTROL S (OUT) 1 minijack
Component Video Input 2 (Y, P
B
, P
R
) Y: 1.0 Vp-p, 75 ohms unbalanced, sync
negative
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
RF Inputs 2
Digital Audio Optical Output
(PCM/Dolby Digital) 1 Optical Rectangular (1)
i.LINK 3 total (1 on front panel) 4-pin S400 i.LINK terminal
Speaker Output 5 W (L), 5 W (R), 20 W (Woofer)
Dimensions (W × H × D) KDF-60XBR950: 1,600 Ч 1,008 Ч 583 mm (63 Ч 39 3 /
4
Ч 23 inches)
KDF-70XBR950: 1,821 Ч 1,143 Ч 647 mm (71 3 /
4
Ч 45 Ч 25 1 /
2
inches)
