User instructions
30
3. Description of the controls
3.1 Front panel
All the dishwasher controls are grouped on the front panel.
1 ON/OFF BUTTON
2 SELECTION PROGRAM BUTTONS (P1…P5)
3 ½ LOAD WASH BUTTON (certain models only)
4 ECO DRYING CYCLE BUTTON (certain models only)
5 DELAY PROGRAM BUTTON (certain models only)
6 START/STOP BUTTON
7 POWER ON LIGHT
8 PROGRAMS INDICATOR LIGHTS
9 INFORMATION DISPLAY
10 RECESSED DOOR HANDLE
3.2 Information display
The dishwasher is equipped with a practical DISPLAY which
provides information on the programmed dishwasher functions.
LIGHTING
Pressing the ON/OFF button (1) will start the dishwasher and will lit up the dishwasher pilot light
(7). After approximately 3 second from this operation the DISPLAY (9) will be turned on with a
visualization that will depend upon the state of the dishwasher.
PROGRAMMING
In this dishwasher model all the programming operations are possible only with closed door. With
open door, on the DISPLAY (9) will appear the symbols -- and the PILOT LIGHT PROGRAMS (8)
remains out.
SELECTION PROGRAM
The program selection is possible through the
relative buttons (2).
By pressing the relative button of desired program (see table) it will lid up the relative pilot light to
confirm that the operation did occurred on the DISPLAY (9) will appear a program duration
forecasting (“h.mm”).
