Supplied hardware, Millimeters, Ca b – Smooth Fitness 7.6HR PRO User Manual
Page 5
www.smoothfitness.com
5
SUPPLIED HARDWARE
This list identifies the hardware you will use to assemble the product. To help distinguish between
the various types of screws and bolts, use the scale below to measure them and compare them to
he sizes listed.
t
No.
Description
Qty.
802 M8 x 45mm Flat Head Bolt
6
806 M6 x 20mm Screw
2
809 M8 x 12mm Allen Head Bolt
4
810 Metal
Cap
2
811 M8 x 80 x 25mm Allen Head Bolt
2
812
4 x 12mm Truss Head Phillips
Screw-Cone Point
8
A 5mm
Wrench
1
B Screwdriver
1
C
6mm Allen Wrench
1
C
A
B
802
806
809
810
811
812
MILLIMETERS
