18 7.6HR PRO TREADMILL
ASSEMBLY
STEP 1: Assemble the Console Support Tube
(A)
Remove your treadmill from the carton and place it on the floor in an open
area as shown in FIG 1.
(B) Then remove the Handlebar Assembly and place them out of the way for
now, as shown in FIG2.
(C) Attach the
Console Support Tube (104) to Upright – Left (205) and
Upright – Right (206), and secure with two M8 x 45mm Flat Head Bolts
(802) .
802 X2
104 205
802
802
206
103
FIG.1 FIG.2
