30

R

Section 7

MAINTENANCE CHART - RECOMMENDED SERvICE INTERvALS (CONT'D)

HOURS

PROCEDURE

COMMENTS

BREAk-IN

(FIRST 10)

8

40

100

200

500

X

Apply grease to fittings

See paragraph 7.2

X

Check hardware for tightness

X

Change engine oil filter

See paragraph 7.4

X

Check hydraulic oil level

See paragraph 7.3

X

Replace engine fuel filter

See paragraph 7.5

X

Drain hydraulic system and
replace hydraulic oil

Use SAE 20W50 Motor Oil.
See paragraph 7.3

X

Replace hydraulic oil filter

See paragraph 7.3

X

Replace cutter deck gearbox
lubricant

See paragraph 7.11

X

Change coolant

See paragraph 7.12

LUBRICATION

7.2

GREASE FITTING LUBRICATION CHART (SEE FIGURE 7-1)

LOCATION

LUBRICATION INTERvAL

LUBRICANT

NO. OF

PLACES

1 Caster Wheel Pivot *

500 Hours/Yearly

Chassis Grease

2

2 Caster Wheel Bearings

100 Hours/Monthly

Chassis Grease

2

3 Cutter Deck Bellcranks

100 Hours/Bi-Weekly

Chassis Grease

4

4 Cutter Deck Pusharms

100 Hours/Bi-Weekly

Chassis Grease

2

5 PTO Spindle

40 Hours/Weekly

+Lithium MP White Grease 2125

1

6 Cutter Deck Spindle

40 Hours/Weekly

+Lithium MP White Grease 2125

3

7 Brake Handle

200 Hours/MonthlY

Chassis Grease

1

8 Cutter Deck Drive Shaft U-Joints

200 Hours/Monthly

Chassis Grease

2

9 Cutter Deck Drive Shaft Slip Sleeve

40 Hours/Weekly

Chassis Grease

1

+ Compatible Greases:

Mobilix #2 found at Mobil Service Stations

Ronex MP found at Exxon Service Stations

Super Lube MEP #2 & Super Stay-M #2 found at Conoco Stations

Shell Alvania #2 found at Shell Service Stations

Lidok EP #2 found at industrial shops

* Remove plug and insert grease zerk. Before filling wth grease, remove dust cap from the top of the pivot.
