32
DIP Switch
DIP Switch Functions
The DM-D500 has two groups of DIP switches.
The functions of the
DIP switches are as follows:
DIP switch 1
(*1)XON/XOFF is effective only when the DM-D500 is connected with a stand alone.
Transmission speed
*Cannot be set to 57,600 or 115,200 when using the IR Series.
DSW1 No.
Function
ON
OFF
Default setting
1-1
Data receive error
Ignored
Displays “?”
OFF
1-2
Hand shaking
XON/XOFF (*1)
DTR/DSR
OFF
1-3
Data length
7 bits
8 bits
OFF
1-4
Parity on or off
Parity
No parity
OFF
1-5
Parity type
Even
Odd
OFF
1-6
Change transmis-
sion speed
See “Transmission speed.”
ON
1-7
OFF
1-8
ON
SW1-6
SW1-7
SW1-8
Transmission speed (bps)
ON
ON
ON
2400
OFF
ON
ON
4800
ON
OFF
ON
9600
OFF
OFF
ON
19200
ON
ON OFF
38400
OFF
ON
OFF
57600*
ON
OFF
OFF
115200*
