5 TP 400-2438-00-AT-SMA
Turbo Clean Sweep Twin Catcher - Hitch Group
1 1921977 2 CAPSCREW, Hex Head, 5/1 6-18 x 1-1/4
2 1705072 1 BRACE, Bar
3 1921210 4 CAPSCREW, Hex Head, 3/8-16 x 1
4 1703844 1 BRACKET, Lower
5 1921959 2 CAPSCREW, Hex Head, 1/4-20 x 5/8
6 1917356 3 LOCKWASHER, 5/16
7 1917372 3 NUT, Hex, 5/16-18
8 1921319 2 WASHER, 1/4
9 1916964 2 LOCKWASHER, 1/4
10 1916622 2 NUT, Hex, 1/4-20
11 1933468 2 WASHER, 5/16
12 1916950 4 NUT, Hex, 3/8-16
13 1916965 4 LOCKWASHER, 3/8
14 1703846 1 SUPPORT
15 1931335 2 CARRIAGE BOLT, 5/16-18 x 1
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691792 Turbo Clean Sweep Twin Catcher
