www.swannsecurity.com
Please note that the information
contained within this document is
subject to change without notification.
Product Specifications
Camera Sensor: 1 /
3
” / 8.5mm Color Super CMOS
TV System: PAL/CCIR (AU, UK, EU)
NTSC/EIA (USA)
Effective Element: PAL: 628 x 582
NTSC: 510 x 492
Definition: 420 TV Lines
Scanning Frequency: PAL/CCIR: 50HZ
NTSC: 60HZ
Minimum Illumination: 3 Lux
Signal Noise Ratio: >+40dB
Electronic Shutter: 1/60 ~ 1/15000second
Noise: <0.03% Peak Value
Power Supply: 8V ~ 12V DC 300mA
View Angle: 40°
Power Control: CDS Light Sensor
Power Consumption: 1.5 Watts
Window: 2mm Heat-Resisting Glass
Construction: Aluminium
Operation Temperture: -4°F ~ 140°F (-20° C ~ 60° C)
Package Contents
HD-420 Security Camera
70ft (22m) Cable with RCA Connectors
Power Adapter
Instruction Manual
The Swann HD-420 Security Camera provides you with crystal clear images when
connect it to your TV, VCR, or Swann Security solution. With a C/CS
inter-changeable lens system you can add the additional lenses*.
The camera comes with a C/CS interchangeable lens system, which gives you
an additional option of lenses. The Swann HD-420 Security Camera is ideal for
domestic to commercial applications to suit your surveillance needs or location.
Note: This camera does not have adjustable e/cs mount collar.
* Large range of additional lenses sold separately
PRO
High Resolution
HD-420™
Security Camera
High Powered, Discreet Surveillance
