4 5 930485 Rev. A 930485 Rev. A
1 1 1 . Y O U R C H A I R A N D I T S P A R T S
Q U I C K I E V - 5 2 1
1
2
3
7
4
5
6
10
15
13
11
12
14
8
9
1. Push Handle
2. Joystick
3. Integral Controller
4. Swing-away Footrest
5. Heel Loop
6. Foot Plate
7. Cross Brace
8. Caster Fork
9. Caster Tire
10. Backrest
11. Drive wheel
12. Motor
13. Battery Box
14. Swing-away
Release Latch
15. Arm Rest
1 1 . T A B L E O F C O N T E N T S
i. Pneumatic Tires .................................................................................... 21
j. Positioning Belts (Optional) .............................................................. 22
k. Push Handles ........................................................................................ 22
l. Rear Wheel Locks (Optional) .......................................................... 22
m.Seating Systems .................................................................................... 23
n. Upholstery Fabric ................................................................................ 23
VIII. TIPS FOR ATTENDANTS .............................................................. 24
a. To Climb a Curb or Single Step........................................................ 24
b. To Descend a Curb or Single Step .................................................. 24
IX. SET UP, ADJUSTMENT & USE .................................................... 25
a. Notes ...................................................................................................... 25
b. Tools You Will Need ............................................................................ 26
c. Check-Out ............................................................................................ 26
d. To Find & Correct A Problem .......................................................... 27
e. Batteries ................................................................................................ 27
f. Swing-Away Footrests ........................................................................ 27
g. Elevating Legrest (Optional) .............................................................. 28
h. Integral Joystick Installation .............................................................. 28
i. Joystick Swing-Away Retractable Mount (Optional).................... 28
j. Dual-Post Height-Adjustable Armrests .......................................... 28
k. Height Adjustable Armrests (Optional) .......................................... 29
l. Rear Wheel Locks (Optional) .......................................................... 30
m.Folding and Unfolding.......................................................................... 30
X. OPERATING GUIDE ........................................................................ 31
a. Performance Control Settings .......................................................... 31
b. Quickie QTRONIX Programming Pad (Optional) ...................... 31
c. Thermal Roll-Back................................................................................ 32
d. Circuit Breakers.................................................................................... 32
e. Integral Controller .............................................................................. 33
f. Motor Locks .......................................................................................... 34
X1. BATTERIES ............................................................................................ 35
a. Introduction .......................................................................................... 35
b. Battery Charger.................................................................................... 36
c. Acid Burns.............................................................................................. 37
d. Connecting Batteries in Battery Box(es) ...................................... 37
e. Charging Batteries................................................................................ 38
f. Disposing of Batteries ........................................................................ 39
XII. MAINTENANCE.................................................................................. 40
a. Notes ...................................................................................................... 40
b. Cleaning .................................................................................................. 40
c. Storage Tips .......................................................................................... 40
d. Battery Maintenance............................................................................ 41
e. Pneumatic Tires .................................................................................... 42
f. To Repair or Replace a Tire .............................................................. 42
g. Motor Brushes ...................................................................................... 43
h. Ordering Parts ...................................................................................... 43
i. Maintenance Chart .............................................................................. 43
XIII. WIRING DIAGRAM .......................................................................... 44
XIV. SUNRISE LIMITED WARRANTY .............................................. 45
