Package contents, Layout – SIIG 04-0444A User Manual
Page 2

2
Package Contents
•
Hi-Speed USB 5-Port PCI
•
This quick installation guide
Layout
Figure 1. Board Layout
* Note: This power connector (same as the one used
with your floppy disk drive) is designed to provide
additional power to the board when needed.
Connect this power connector (recommended) when
one of the following conditions occur:
- Device(s) not being detected.
- All ports are used.
Power off your system first before making this
connection.
External
ports
USB Pin-out
Header
Power connector
(Optional)*
Internal port
