Sierra Monitor Corporation PF5M User Manual

Page 2

Safety Instructions

Names and Functions of Individual Parts

Model Indication Method

Mountin and Installation

Installation

Pipimg

Wiring

Error Indication

Thank you for purchasing the SMC PFM5

Series Digital Flow

Sensor.
Please read this manual carefully before operating the digital
flow sensor and make sure you understand the digital flow
sensor, its capabilities and limitations.
Please keep this manual handy for future reference.

OPERATOR

• This manual has been written for those who have knowledge of

machinery and apparatuses that use pneumatic equipment and have
full knowledge of assembly, operation and maintenance of such
equipment.

• Please read this manual carefully and understand it before assembling,

operating or providing maintenance service to the flow sensor.
