Specifications
1. APPLICATION
Model S-450
2. POWER SOURCE
AC 230V, 50Hz, 15W
3. DIMENSIONS
348 (W)x 246 (D)x 106 (H) mm
4 WEIGHT
3.2 Kgs
5. CHARACTERISTICS (TEST DISC: TCD-782, LOAD=47Kohm)
ITEM
TYPICAL LIMIT CONDITION
(1) Output level 1Vrms+/-0.5dB 1Vrms+/-1dB 1KHz,0dB
(2) Channel balance within 0.5dB within1dB 1KHz,0dB
(3) Frequency response 20-20KHz,+/-0.5dB 20-20KHz,+/-1dB 0dB output
(4) De-emphasis response +/-2.5dB +/-3dB 16KHz,-20dB
(5) Channel separation 83dB 75dB 1KHz,0dB
(6) T.H.D. + NOISE*1 0.01% 0.03% 1KHz,0dB
(7) S/N ratio*2 86dB 80dB 1KHz,0dB
NOTE: *1 With 20KHz low pass filter.
*2 With 20KHz low pass filter, ”IHF-A” weighted.
6. SEARCHING TIME (TEST DISC: TCD-792)
ITEM
TYPICAL LIMITS CONDITION
(1) Short access time 2sec 4sec Play next track
(2) Long access time 4sec 6sec Track 1 ->Track 20
Track 20 ->Track 1
7. PLAYABILITY
ITEM TYPICAL LIMIT CONDITION
(1) Interruption 1mm 0.7mm TCD-725
(2) Black dot 1mm 0.6mm TCD-725
(3) Finger prints 75um 65um TCD-725
(4) Eccentricity 140um 140um TCD-712 W/O TRACK JUMP
(5) Vertical deviation 1mm 0.5mm TCD-731R
8. PICK -UP
(1)
System Object lens drive system optical pick-up
(2) Object lens drive system 2 dimensional paralled drive
(3) Tracking detection 3 spot beam detection
(4) Optical source Semiconductor laser
(5) Wave length 780nm
9. GENERAL
(1)
System Compact Disc Digital Audio
(2) Disc loading Front loading
(3) Display LCD
(4) Pitch control range Within +/-4%,+/-8%, +/-16%, +/-100%
(5) Pitch bend +/-100%
(6) Pitch accuracy 0.1 %
10. ENVIRONMENTAL
CONDITION
(1) Operating Temperature 5 to 35 deg. C
(2) Humidity 25 to 85% RH (non-condensing)
(3) Storage Temperature -20 to 60 deg. C
11. ACCESSORIES
(1)
Connected RCA cable 1 set for L and R channel
(2) Operating Instruction 1 pc
12. NOTES
(1)
The specifications are subject to change to any improvement by negotiations in advance.
(2) The parts are subject to change to any improvement within the range of the specifications.
