English Mode 3: Stick Vacuum
3 With the Dust Cup end facing
upward, guide the attached Hose
Mounting plate onto the two pins on
either side of the Backsaver™ Wand.
4 Snap the shorter end of the Flexible
Hose into lower connection on the
Hand Vac (both Hose ends are the
same).
Snap other end of the Flexible Hose
to upper connection on Backsaver™
Wand.
The single wheel of the Hand Vac
fits into the holder just below
the pins.
5 Tighten the Hand Vac Locking Dial to
secure onto Backsaver™ Wand.
STICK VAC
In Stick Vacuum Mode, you have
constant suction power with the
added swivel steering capabilities
of the Shark® Swivel Floor Nozzle:
1 Remove Air Dam from Hand Vac and
place the Air Dam in the slot on the
Hand Vac exhaust filter cover.
2 Slide Hose Mounting Plate into
grooves on the underside of the Dust
Cup so that Hose Mount assembly
covers the inlet on Hand Vac.
CAUTION: The Power Button for
all three modes is on the Hand Vac
handle. Always turn the power OFF
before plugging and unplugging,
when adding or removing
attachments, or when connecting
Hand Vac to or from the
Backsaver™ Wand.
Your Stick vacuum can be
carried by the pet hair power
brush holder.
2
3
4
5
1
