7
TP-400-2086-03-LL-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692784 Landlord 16HP Hydro
1692788 Landlord 18HP Hydro
1692790 Landlord 16HP Hydro - Exp
1692794 Landlord 18HP Hydro - Exp
1692837 1716H, 16HP Hydro
1692841 1718H, 18HP Hydro
1692843 2718H, 18HP Hydro
1693008 Landlord, 16HP Hydro
1693010 Landlord, 16HP Hydro - Exp
1693016 Landlord 18HP Hydro
1693018 Landlord 18HP Hydro - Exp
Engine & Electric Clutch - 16HP & 18HP Briggs & Stratton
1
1706692
1
ELECTRIC CLUTCH (Incl. Ref. Nos. 2, 3, & 4)
2
1707586
1
FIELD ASSY., Clutch
3
1685487
1
ROTOR ASSY./ARMATURE KIT
4
1707587
1
SPRING & NUT KIT
5
*
ENGINE 16 HP Briggs & Stratton, Vanguard Model 303777
5
*
ENGINE 18 HP Briggs & Stratton, Vanguard Model 350777
6
1704343
1
DRAIN, Oil
7
1667346
1
CAP, Oil
8
1960112
2
CLAMP, Hose
9
1676861
1
HOSE, Fuel, 45.5” Long
10
1960536
1
SCREW, Plastite, 1/4-10 x 1/2
11
1713846
1
KNOB, Throttle
12
1714068
1
THROTTLE & CABLE ASSY.
13
1703956
1
SWITCH, Oil Pressure
14
1704344
1
CABLE, Choke Control
15
1704419
2
BELT STOP
16
171241
1
KEY
17
1713187
1
PULLEY ASSY.
18
1924940
2
WASHER, Plain, 13/32
19
1930598
4
SCREW, Taptite, 3/8-16 x 1-1/2
20
1708587
1
SPACER
21
1708264
1
WASHER
22
1918199
1
LOCKWASHER, 7/16
23
1960458
1
CAPSCREW, 7/16-20 x 4
24
1703986
1
MANIFOLD, Exhaust
25
1676183
1
CLAMP, Muffler
26
1931342
1
CARRIAGE BOLT, 5/16-18 x 2-3/4
27
1935255
1
NUT, Pal, 5/16-18
28
1703971
1
MUFFLER ASSY.
29
1704357
1
DUCT, Lower Muffler
30
1960368
4
NUT, Pal, 1/4-20
31
1919326
2
WASHER, Plain, 11/32
32
1917356
2
LOCKWASHER, 5/16
33
1917372
1
NUT, Hex, Full, 5/16-18
34
1921333
1
CAPSCREW, Hex Hd., 5/16-18 x 1
35
1703908
4
SCREW, Metric
37
920427
1
LOCKWASHER, External Tooth
38
1707334
1
DUCT, Upper Muffler
39
1960295
4
SCREW, Flange Whiz, 1/4-20 x 5/8
40
934683
1
CLIP
Footnotes:
* See your local Briggs & Stratton distributor for service parts.
