Steering – Simplicity LANDLORD 2700 User Manual
Page 7
5
TP-400-2086-03-LL-SMA
Steering
1
1686651
1
STEERING WHEEL, 15” (Incl. Ref. No. 2 & 3)
2
1714097
1
CAP, Steering Wheel
3
1960540
1
PIN, Spring, 5/16 x 2-1/2
4
1714400
1
TUBE, Steering
5
1714884
1
SHAFT ASSY., Steering
6
1919314
1
COTTER PIN
7
1960114
13
WASHER, Plain, 49/64
8
173668
1
WASHER, Plain
9
1960020
2
WASHER
10
1703508
1
PLATE, Mounting, Steering
11
1928352
2
NUT
12
176440
3
BUSHING, Nylon
13
1921221
1
CAPSCREW, Hex Hd., 5/16-18 x 1-1/2
14
1928721
2
SETSCREW, Sq. Hd., 5/16-18 x 1/2
15
1703513
1
GEAR ASSY., Steering
16
1716117
1
SECTOR MOUNTING PLATE
17
1960373
2
SCREW, Taptite, 5/16-18 x 3/4
18
1707431
1
PITMAN ARM ASSY.
19
930670
1
KEY, Hi Pro
20
1673796
1
SPACER, Stop
21
1919438
1
NUT, Hex, Lock ESNA Light, 5/16-18
22
1685478
1
DRAG LINK ASSY. (Incl. Ref. Nos. 23, 24, 25, 26, 27, 28 & 29)
23
1921968
2
CAPSCREW, Hex Hd., 3/8-16 x 1-3/8
24
1708236
2
SPACER
25
1702779
2
ROD END
26
1922755
2
WASHER
27
1930645
4
NUT, Hex, Lock, Flange, 3/8-16
28
1919262
2
NUT, Hex, Jam, 1/2-20
29
1708084
1
DRAG LINK
30
1704420
2
KLIP RING
31
1706997
1
ARM ASSY., Steering, LH
32
1706991
2
SPINDLE ASSY.
33
1706956
1
TIE ROD
34
1611705
2
SPACER
35
1706996
1
ARM ASSY., Steering, RH
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692784 Landlord 16HP Hydro
1692786 Landlord 17HP LC Hydro
1692788 Landlord 18HP Hydro
1692790 Landlord 16HP Hydro - Exp
1692792 Landlord 17HP LC Hydro - Exp
1692794 Landlord 18HP Hydro - Exp
1692837 1716H, 16HP Hydro
1692839 1717H LC, 17HP LC Hydro
1692841 1718H, 18HP Hydro
1692843 2718H, 18HP Hydro
1692854 2717H LC, 17HP LC Hydro
1693008 Landlord, 16HP Hydro
1693010 Landlord, 16HP Hydro - Exp
1693012 Landlord 17HP LC Hydro
1693014 Landlord 17HP LC Hydro-Exp
1693016 Landlord 18HP Hydro
1693018 Landlord 18HP Hydro - Exp
