WASHING TIME
The amount of detergent
is average. Follow the
instruction printed on the
package for amount of
detergent. Choose the
amount of detergent
according to the fabric type.
TYPE OF FABRIC
Thin (synthetic fiber)
wool
cotton
thick (cotton)
SPIN DRY TIME
DETERGENT
TIME
1 min.
1~2 min.
3~5 min.
5 min.
AMOUNT OF
DETERGENT
44g
56g
67g
WATER
LEVEL
Low (44 l )
Medium (56 l )
High (67 l )
DETERGENT
In case the water level is at “High”,
amount of water is 42
l .
Follow the directions printed on the package
for amount of detergent. Choose the amount of
detergent depending on the fabric type and
water level.
LAUNDRY GUIDE
-H-
Leave some space of
at least 15cm between the washing machine
and the wall.
Place the washing machine on a sturdy flat
surface.
If the washing machine is placed on an uneven
or weak surface, noise or vibration may occur.
(Allowable is 2˚)
Never install the washing machine near water.
Do not place the washing machine in steamy room or
where the washing machine is directly exposed to
rain. Moisture may damage electrical insulation
and cause an electrical shock to occur.
Avoid direct sunlight or heating devices.
As plastic and electrical components are
affected by direct heat, never place the washing
machine near heaters, boilers, etc., or under direct
sunlight.
Install the drain hose
about 70~80cm above
the ground for pump model.
MOUNTING THE LEGS
Lay down the washer with its back facing
downward. Insert four legs into the leg mounting
sections of the base corners of the main body.
Insert the claw of the
leg with the square
hole of the leg
mounting section,
and push the leg in
the arrow direction
as shown in the
figure until it clicks.
After attaching the connector ring(a), insert the
drain hose(b) in the draining direction.
CONNECTING THE DRAIN HOSE
1. Before connecting the drain hose, remove
the cover (a) from the drain hole.
2. After pressing the joint ring (b), insert the
drain hose(c) to drain direction.
CHANGING THE POSITION OF THE
DRAIN HOSE
Before attempting to change the position of the
drain hose, disconnect the plug from the outlet.
1. Route the drain hose inside the machine.
2.Take out the drain hose from the opposite hole
and insert the drain hose into the hose holder.
70~80cm
Claw
Square
hole
Bottom face of
main body
Leg
1
2
INSTALLATION
LOCATION CONNECTING THE DRAIN HOSE
a
b
(In case of pump
drained washer)
(C)
(b)
(C)
(b)
(a)
2
1
Hose holder
Water Level
Sgurts (Synthetics)
Under Shirts (Cotton)
Workign clothes (Cotton)
Low
22 Pieces
38 Pieces
16 Pieces
Middle
29 Pieces
48 Pieces
20 Pieces
High
35 Pieces
58 Pieces
25 Pieces
5
