Channel Level Meter
14
3.2.9
Channel Level Meter
FX
E
E
FX
MASTER
Figure 3.17
The Channel Level Meter indicates the volume of each channel like
a traditional DJ mixer. (Figure 3.17)
3.2.10
Channel Strip
FX
E
E
FX
MASTER
Figure 3.18
The Slider, Button, Mode Switchers, Channel Fader, Level Meter, and
Monitor Button all constitute a traditional channel strip. The Channel
Strip can be switched between decks A/C on the left side and B/D
on the right side of the SCS.3m to control up to 4 software channels.
(Figure 3.18)
