Apply Height Adjustment and Moving Label (33) to front of
pole, where it is clearly visible.
11.
12.
B. D. C. A.
Install net (43).
34
39
28
Cover plate (28) will fit
INSIDE back bracket.
NOTE:
43
34
43
34
13.
RIM COVER ATTACHMENT
39
566200 12/05
HEIGHT ADJUSTMENT
TO ADJUST BACKBOARD:
1. Grasp handle and press button.
2. Raise or lower to desired height.
3. Release button.
MOVING SYSTEM
Adjust basketball backboard
height to lowest position.
While holding pole, rotate
basketball system forward
until wheels engage with
ground.
Move basketball system to
desired location.
Carefully rotate basketball
system upright.
1.
2.
3.
4.
5. Check system for stability.
4
2
1
3
33
