OPERATION
CY72 01/08 Operation Section 4-3
© 2008 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
CY72
Horsepower Required (Min.) 40 HP
Cutting Capacity (Max.) 4”
Cutting Height 1-9/16”
Safety Deflector Rubber Belting
Cutting Width 72”
Overall Width 79-1/4”
Overall Length 118”
Base Unit Weight (Approx.) 1338 lbs.
Hitch CAT II
Blade Carrier Pan
Blades 1/2” x 4” Updraft
Gearbox Rating:
540 RPM 150 HP*
1000 RPM 150 HP*
Output Shaft Diameter 2-3/8”
Blade Tip Speed:
540 RPM 13,996 FPM
1000 RPM 13,709 FPM
Driveline Size Cat 5
Driveline Protection Slip Clutch
Deck Thickness 3/16”
Side Skirt 1/4” x 10-3/4”
Tires & Wheel Laminated
*Ratings based on actual field performance.
The Mower is designed for certain mowing applications and is rated to cut up to a specific
size vegetation (see Mower Standard Equipment and Specifications). DO NOT use this
mower to cut vegetation above the Mower’s rated capacity or to cut any type of non-vegetative material. Only
operate this Mower on a properly sized and equipped Tractor. Operating this Mower in an application for
which it is not designed and/or operating the Mower with the wrong size Tractor can cause Mower component
damage and equipment failure resulting in possible serious injury or death.
(SGM-14)
