Specifications
21
03
ENGINE
Make ................................................................Tecumseh
Cylinders........................................................................1
Cycles.............................................................................4
Crankshaft .......................................................Horizontal
8 HP
- Model No. .....................................See engine I.D. plate
- Bore & Stroke ..............................3-1/8 in. x 2-17/32 in.
(79.90 mm x 64.31 mm)
- Displacement .............................................19.43 cu. in.
(318.30 cc)
Ignition ...............................................................Magneto
Governor........................................................Mechanical
Choke ...................................................................Manual
Lubrication ...............................................Splash system
Oil Capacity ......................................See engine manual
Fuel Capacity....................................See engine manual
TRACTION DRIVE
Type...........................Friction drive transmission w/chain
gear drive and speed selection
Speeds ...............................Five forward and two reverse
Axle ....................Solid w/klik-pin lock for two-wheel drive
Tire Inflation ..........................................20 psi (137 kPa)
AUGER HOUSING
Construction..............................Welded steel stampings
Effective Width
- Model 8-60M ............................................24 in. (60 cm)
Auger Opening Height ...........................19 in. (47.5 cm)
Spout Rotation ............................................210 degrees
Scraper Bar.................High Carbon, wear resistant steel
Skid Shoes ........................Adjustable, heat-treated steel
AUGER
Construction.............................Ribbon flite welded steel
Bearings ...................................................Self-lubricating
IMPELLER
Construction..............................................4 steel blades
Bearings ..............Pre-lubricated and sealed ball bearing
Diameter.....................................................12 in. (30 cm)
AUGER & IMPELLER DRIVE
Type....................Cushion V-belt and worm gear housing
OVERALL DIMENSIONS & WEIGHT
Model 8-60M
- Length ....................................................54 in. (137 cm)
- Width ........................................................26 in. (65 cm)
- Height.....................................................43 in. (109 cm)
- Weight .................................................236 lbs. (107 kg)
SPECIFICATIONS ARE CORRECT AT TIME OF
PRINTING AND ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
