6. CONTROL PANEL
LED Display
A.C. POWER (red) LED lit:
There is AC power supplied to the battery charger.
CHARGING
(yellow) LED lit:
The charger is charging the battery.
CHARGING
(yellow) LED flashing:
The charger is in abort mode.
CHARGED
(green) LED lit:
The battery is fully charged and the charger is in maintain mode .
CHARGED (green) LED flashing:
The battery is 80% charged and is ready to use.
7. OPERATING INSTRUCTIONS
This battery charger must be properly assembled in accordance with the
assembly instructions before it is used.
Battery Information
This charger can be used with 16 and 24V batteries; it automatically detects your battery type.
Charging
NOTE: Examine the battery for excessive wear, cracks, bulging or damage each time you
charge it. If damage is detected, do not charge the battery, replace it immediately. If the
battery is hot, allow it to cool before charging.
1. Connect the battery following the ride-on toy’s instruction manual.
2. Connect the AC power following the precautions listed in section 3.
3. If you’ve connected everything correctly, the CHARGING
LED should be lit,
indicating that the charger is charging.
This charger does not have an ON/OFF switch. ON and OFF are
controlled by plugging in the charger to the AC wall outlet. The charger will
not supply current to the battery clips until a battery is properly connected. The clips will
not spark if touched together.
Using the Quick Cable XLR Connector
1. Connect the output cable assembly to the charger. Make sure to place the charger
on a dry, non-flammable surface, such as metal or concrete.
2. With the charger disconnected from the wall outlet, connect the supplied harness
assembly by connecting the yellow connector to the yellow connector on the end of
the charger cable. Connect the other end of the cable assembly to the battery.
NOTE: See Replacement Parts for more connector information.
NOTE: Never connect the output cable assemblies together for use in other applications,
such as external battery or other power source charging, or to extend the output cable
length, as reverse polarity and/or overcharge conditions will occur.
Quick Charge
When the CHARGED LED begins to flash, the battery is ready to use. Unplug the
charger from the wall outlet and then disconnect the charger from the battery. NOTE: The
CHARGING LED will remain lit while the CHARGED LED is flashing.
Complete Charge
When the CHARGED LED stops flashing and stays lit and the CHARGING LED
turns off, the battery is completely charged and the charger has stopped charging and
switched to the Maintain Mode of operation. When ready to use, unplug the charger from
the wall outlet and then disconnect the charger from the battery.
NOTE: For longer battery life, the battery must be completely charged after two
consecutive quick charges. (Example: quick-quick-complete.)
