Snapper 210400 - Manual (Page 16)

210400
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5121--16 Assemblies include all parts shown in frames. 10/07/2008
16
1051 691265 Ring--Retaining
Used on Type No(s).
0127, 0132, 0134,
0137, 0138, 0140,
0141, 0142, 0152,
0193.
1052A 791159 Sensor Oil
1054 280275 Tie--Cable
1058 277040 Manual--Operator’s
-------------- Note ----------
MS3780 Manual--
Operator’s
Used on Type No(s).
0046, 0105, 0192,
0535, 0536, 0546,
0570.
1070 690364 Screw
(Flywheel Fan)
1090 691293 Retainer--Brush
1095 695440 Gasket Set--Valve
1100 791959 Pivot--Rocker Arm
1119 691183 Screw
(Alternator)
1127A 695407 Screw--Float Bowl
1138 694255 Nut
(Control Bracket)
1171 696754 Stud
(Rocker Cover)
1177 710090 Nut
(Muffler)
1194 691876 Seal--O Ring
(Plug)
1210 498144 Pulley/Spring
Assembly
(Pulley)
1211 498144 Pulley/Spring
Assembly
(Spring)
1230 791754 Stud
(Control Bracket)
1298 696757 Nut
(Heat Shield)
1319 794467 Label--Warning
1404 696757 Nut
(Control Cover)
K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121A.
∆ Included in Valve Gasket Set--Ref. No. 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
