Snapper 210400 - Manual (Page 14)

210400
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5121--14 Assemblies include all parts shown in frames. 10/07/2008
14
358 695438 Gasket Set--Engine
361 691681 Screw
(Starting Switch)
361A 690297 Screw
(Starting Switch)
363 19203 Puller--Flywheel
364A 699947 Terminal--Oil Plug
369 695422 Spring--Float Bowl
383 19374S Wrench--Spark Plug
410 695382 Link--Control
415 691363 Plug
425 694515 Screw
(Air Cleaner Cover)
425A 790043 Screw
(Air Cleaner Cover)
436C 792374 Manifold--Exhaust
437 696705 Screw
(Exhaust Manifold)
445 491588S Filter--Air Cleaner
Cartridge
445A 695302 Filer--Air Cleaner
Cartridge
Used on Type No(s).
0186.
455 694683 Cup--Flywheel
-------------- Note ----------
697357 Cup--Flywheel
Used on Type No(s).
0145.
456 692299 Plate--Pawl Friction
459 281505S Pawl--Rachet
467
691668 Knob--Air--Cleaner
Used on Type No(s).
0186.
474A 695730 Alternator
(DC Only)
Used on Type No(s).
0134.
474D 695466 Alternator
(10--16 Amp
Regulated))
Used on Type No(s).
0132, 0142, 0152,
0193.
493 694861 Bracket--Mounting
Used on Type No(s).
0070, 0111, 0114,
0134, 0135, 0140.
493A 691177 Bracket--Mounting
Used on Type No(s).
0132, 0142, 0152,
0193.
500 691086 Washer
(Key Switch)
500A 792613 Washer
(Key Switch)
501 691185 Regulator
Used on Type No(s).
0132, 0142, 0152,
0193.
503 691532 Strap--Starter
504 695383 Washer Set--Friction
505 691251 Nut
(Governor Control
Lever)
510 693699 Drive Starter
513 692024 Clutch--Drive
522 697689 Plug--Dipstick/Fill
Used on Type No(s).
0114, 0136, 0137.
523 695344 Dipstick
524 691876 Seal--Dipstick Tube
525 695343 Tube--Dipstick
526 690297 Screw
(Regulator)
529 791822 Grommet
544 692034 Armature Starter
552 694674 Bushing--Governor
Crank
562 793216 Bolt
(Governor Control
Lever)
564 692577 Screw
(Control Cover)
564A 692198 Screw
(Control Cover)
575 692303 Switch--Starter
577 690630 Cable Starter
577A 690795 Cable Starter
578 692306 Wire Assembly
578A 790948 Wire Assembly
579 691029 Nut
(Starter Cable)
592 690800 Nut
(Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp--Hose
604 697326 Cover--Control
604A 791752 Cover--Control
608 695287 Starter--Rewind
613 695312 Screw
(Muffler)
613A 695399 Screw
(Muffler)
615 694676 Retainer--Governor
Shaft
(Governor Gear)
616 694675 Crank--Governor
621 692310 Switch--Stop
622 698839 Washer
(Heat Shield)
627 696064 Panel
627A 792608 Panel
632 695917 Link--Throttle
(Use With Nikki
Carburetor)
633B
D
690998 Seal--Choke/Throttle
Shaft
635 691909 Boot--Spark Plug
636 691029 Nut
(Starting Switch)
(1/4” Diameter)
-------------- Note ----------
696198 Nut
(Starting Switch)
(5/16” Diameter)
641 691075 Washer
(Starting Switch)
641A 690282 Washer
(Starting Switch)
654 690958 Nut
(Carburetor)
663 692577 Screw
(Control Panel)
-------------- Note ----------
690372 Screw
(Control Panel)
Used on Type No(s).
0134, 0152.
664 691087 Nut
(Key Switch)
668 694257 Spacer
(Control Bracket)
668A 693604 Spacer
676 393761 Deflector--Muffler
(Side Out)
677 690661 Screw
(Muffler Deflector)
689 691855 Spring--Friction
695 698807 Screw
(Ring Gear)
697 690372 Screw
(Drive Cap)
718 690959 Pin--Locating
718A 695178 Pin--Locating
K Included in Engine Gasket Set--Ref. No. 358.
D Included in Carburetor Overhaul Kit--Ref. No. 121A.
∆ Included in Valve Gasket Set--Ref. No. 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
