9
Setup & Installation
Initial Setup & Installation
Figure 3. Lift Components - Mowing
A. Clevis Pin
B. 5/15-18 x 1 Capscrew (Gr. 5)
C. Washer
D. Lift Link (Original)
E. Lift Lock
F. Lift Lever
G. Locknut
H. Hair Pin Clip
I.
Spacer
J. Lift Cam
K. Mower Hole
Figure 4. Lift Components - Tilling
A. Clevis Pin
B. 5/16-18 x 1 Capscrew (Gr. 5)
C. Washer
D. Lift Link (New)
E. Lift Lock
F. Lift Lever
G. Locknut
H. Hair Pin Clip
I.
Spacer
J. Lift Cam
K. Tiller Hole
L. 5/16-18 x 1 Capscrew (Gr. 8) (New)
M. Lock Plate
J
A
K
B
C
G
D
E
F
H
I
A
B
C
E
F G
K
I
H
M
L
J
D
