TROUBLESHOOTING AND MAINTENANCE
91
8
Transfer charger
1 Turn the power switch off. (p.17)
2 Ensure that the bypass tray is open and then open the side
cover while pressing the side cover open button. (p.80)
3 Take the charger cleaner out by holding the tab. Set the charger
cleaner onto the right end of the transfer charger, gently slide
the cleaner to the left end, and then remove it. Repeat this
operation two or three times.
4 Return the charger cleaner
to its original position.
Close the side cover by
pressing the round
projections near the side
cover open button.
5 Turn the power switch on. (p.16)
Slide the charger cleaner from the right end to the left end along the
groove of the transfer charger. If the cleaner is stopped on the way,
smudges on copies may occur.)
Note
