11
Diagrams
HYDRAULIC PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 72-079 Suction Hose 2
2 18-276 Tee Fitting 1 1 /
4
1
3 60-215 Filter 1
60-334 Filter Element (replacement only) 1
4 72-096 Hydraulic Tank 1
5 34-058 Swivel Tee 1
6 72-065 Hydraulic Hose 1
7 72-040 Cylinder 1
72-040-01 Seal Kit 1
72-040-02 Pin with Clips (part of 72-040) 2
8 72-064 Hydraulic Hose 1
9 72-070 Hydraulic Hose 1
10 72-071 Hydraulic Hose 2
11 10-187 Hydraulic Cylinder 1
14-273 Seal Kit 1
12* 72-022 Hydraulic Motor (Thatch Reel) 1
78-219-01 Seal Kit 1
78-219-02 Drive Coupler 1
13 72-073 Hydraulic Hose 2
14 72-044 Quick Coupler 3 /
8
Male End 1
15 72-045 Quick Coupler 3 /
8
Female End 1
16 72-072 Hydraulic Hose 1
17 18-170 Tee Fitting 1
18* 78-219 Hydraulic Motor (Reel) 1
78-219-01 Seal Kit 1
78-219-02 Drive Coupler 1
19 72-075 Hydraulic Hose 1
20 72-074 Hydraulic Hose 1
21 72-043 Quick Coupler ½ Male End 4
22 72-046 Quick Coupler ½ Female End 4
HRR-150 Retaining Ring 1½" External 8
23 72-068 Hydraulic Hose 2
24 72-074 Hydraulic Hose 2
25 72-067 Hydraulic Hose 2
26 72-063 Hydraulic Hose 1
27 33-066 Hydraulic Valve 1
28 72-069 Hydraulic Hose 1
29 78-416 Hydraulic 3 Bank Valve 1
30 72-062 Hydraulic Hose 1
31* 72-021 Hydraulic Pump (Double Pump) 1
72-021-01 Seal Kit 1
32 72-066 Hydraulic Hose 1
* No other parts are replaceable for hydraulic motor or pump.
HYDRAULIC PRESSURES FRONT REAR
Pump Displacement .90 in 3 /rev .40 in 3 /rev
Pump Input Speed (up to) 4000 rpm 4000 rpm
Max. Operating Pressure 3600 psi 3600 psi
Max. Inlet Vacuum 10 in. Hg 10 in. Hg
Max. Case Pressure 80 psi 80 psi
