User instructions
30
3. Description of the controls
3.1 Front panel
All the dishwasher's controls and indicators are located on the front panel, with layout varying
depending on the models. Check whether your panel is Type "A" or "B" and then identify the
control and monitoring devices in the key below.
T YPE "A" T YPE "B"
1 WASHING PROGRAM SELECTOR
2 ON / OFF AND DELAYED START SELECTOR
3 ON / OFF BUTTON
4 POWER ON LIGHT
5 START/STOP BUTTON
6 ½ LOAD WASH BUTTON
7 ECO DRYING CYCLE BUTTON (certain models only)
8 INFORMATION DISPLAY
9 ½ LOAD WASH LIGHT
10 ECO DRYING CYCLE LIGHT
11 NO SALT LIGHT / HEATING ELEMENT LIGHT (depending on models)
12 RINSE AID WARNING LIGHT
13 DELAYED START SELECTOR
14 RECESSED DOOR HANDLE
3.2 Information display
The dishwasher is equipped with a practical DISPLAY which provides information on
the programmed dishwasher functions.
