Specifications cell type kr-1100ael, Typical characteristics, Inch

background image

Typical Characteristics

Specifications

Cell Type KR-1100AEL

Dimensions

of

Bare Cell

H

42.0

±0.3

mm

1.654

±0.012

inch

D

16.5

±0.2

mm

0.650

±0.008

inch

d

8.5

mm

0.335

inch

D

d

H

Nominal Capacity

1100mAh

Nominal Voltage

1.2V

Charging Current

Standard

110mA

Fast

1700mA

Charging Time

Standard

14 to 16Hrs.

Fast

about 1Hr.

Ambient
Temperature

Charge

Standard

0°C to +45°C [+32°F to 113°F]

Fast

0°C to +45°C [+32°F to 113°F]

Discharge

-20°C to +60°C [ -4°F to 140°F]

Storage

-30°C to +50°C [ -22°F to 122°F]

Internal Impedance (Av.)
(at 50% discharge)

9.0m

(at 1000Hz)

Weight

28g/0.99oz

Dimensions(D)

×(H)

(with tube)

Charge

1.6

1.5

1.4

1.3

0

2

4

6

8

10

12

14

16

Charge : 110mA

0˚C/32˚F

20˚C/68˚F

45˚C/113˚F

Cell Voltage (V)

Charge Time (Hrs.)

Charge

1.6

1.5

1.4

1.3

0

20

40

60

80

100

120

140

160

1.5 It

0.1 It

Cell Voltage (V)

Charge Input (%)

Temperature :

20˚C/68˚F

Discharge (at low rate)

1.4

1.2

1.0

0.8

0

2

4

6

8

10

12

14

16

Charge : 110mA

×16Hrs.

at 20˚C/68˚F

(0.1 It)

(0.2 It)

(0.5 It)

Cell Voltage (V)

Discharge Time (Hrs.)

Discharge (at high rate)

1.4

1.2

1.0

0.8

0

10

20

30

40

50

60

70

80

Charge : 110mA

×16Hrs.

at 20˚C/68˚F

(2 It)

(1 It)

Cell Voltage (V)

Discharge Time (Mins)

Discharge (at high rate)

1.4

1.2

1.0

0.8

0

2

4

6

8

10

12

14

16

Charge : 110mA

×16Hrs.

at 20˚C/68˚F

(4 It)

(8 It)

Cell Voltage (V)

Discharge Time (Mins)

Temperature (Charge & Discharge)

100

80

60

40

-20

-10

0

10

20

30

40

50

60˚C

-4

14

32

50

68

86

104

122

140˚F

Available Capacity (%)

Operating Temperature

90

70

50

Charge Characteristics
Discharge Characteristics

Condition Charge : 110mA

×16Hrs.

Discharge : 220mA
(End Volt 1.0V)

17.0

0

× 43.0

0

mm

-0.5

-1.2

0.67

0

× 1.69

0

inch

-0.02

-0.05

CD010830
