REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1 387903 MAIN FRAME (ASM.) 1
2 387106 X MOTOR BRACKET (ASM.) 1
3 387365 X AXIS STM 1
4 387108 X MOTOR GEAR 1
5 386522 SCREW 2
6 386493 SCREW 2
7 386377 INTERMEDIATE GEAR A 1
8 283459 E RING 1
9 283497 SCREW 3
10 283474 SCREW 1
11 387313 X COORDINATE SUBORDINATE DRIVE GEAR 1
12 387314 PULLEY FLANGE 1
13 283460 E RING 1
14 387110 X DRIVE BELT 1
15 387315 X PULLEY (ASM.) 1
16 283474 SCREW 1
17 387891 X COORDINATE DRIVE SHAFT 1
18 387114 X COORDINATE DRIVE SHAFT FELT B 1
19 387135 SCREW 2
20 387115 BELT PRESSER A 1
21 387116 BELT PRESSER B 1
22 387136 SCREW 2
23 283523 SCREW 1
24 283322 CORD HOLDER 1
25 387366 X AXIS DETECTING SWITCH (ASM.) 1
26 387302 NUT 1
27 283485 SCREW 1
28 387135 SCREW 1
29 387142 SCREW 1
30 387895 X COORDINATE DRIVE PLATE (ASM.) 1
31 * 387894 X COORDINATE DRIVE PLATE (1)
32 * 387892 X COORDINATE DRIVE BEARING A (2)
34 * 387120 X DRIVE SHAFT RECEPTACLE HOLDER (2)
33 283469 SCREW (2)
35 283335 START SWITCH LEAD TAPE 1
36 387367 Y AXIS STM 1
37 387122 Y MOTOR GEAR 1
38 386522 SCREW 2
39 386493 SCREW 2
40 387123 CORD HOLDER PLATE 1
41 386609 SCREW 2
- 44 -
