Speco Technologies 10X PAN-TILT HTSD10X - Manual (Page 28)

28
MODEL HTSD10X
Pan Rotation Angle 360 ˚ Endless
Manual 10 ˚ ~ 200˚/sec
Pan Speed
Preset Max 200 ˚ /sec
Tilt Rotation Angle 0 ˚ ~ 90˚
Manual 10 ˚ ~ 200˚/sec
Tilt Speed
Preset Max 200 ˚ /sec
PAN /TILT
System Accuracy 0.02 ˚
Presets
164 positions with a 16-character label available for each position
with different speed steps
Group Tour
Max. 8 Programmable group tours (each one consisting of up to 60 preset steps
with different steps)
Auto scan Programmable Auto scan
Pattern 8 Programmable Patterns (total 400 seconds)
Privacy Zone 4 privacy zones
Sector 8 selectable Sectors with 16 characters
Password Protection Yes
Alarm Input 4 alarms OFF/NC/NO (with various programmable states)
Alarm Actions Activate preset, Group scanning or Patterns
Auto Flip ON / OFF
OSD Menu Multiple Languages on screen
Communication RS-485
FUNCTIONS
Protocol Pelco D/P
Power Consumption 9W Max
POW ER
Power Supply 12VDC 750mA
Construction Die-cast , Anti-vandal dome cover
Dimensions 167.0 φ (D) * 167.0mm(H)
W eight 1.5 kg
Motor Type Stepper Motor
Micro Steps 1/4 Step
Storage Temperature -40F to +140F
Operating Temperature -14F to +120F
OTHERS
Certifications CE, FCC
Image Sensor 1/4" Sony Super HAD CCD
NTSC 811(H) * 508(V) 410K Total
Pixels
PAL 795(H) * 596(V) 470K
NTSC 768(H) * 494(V) 380K Number Of
Effective
Pixels
PAL 752(H) * 582(V) 440K
Horizontal resolution More Than 500TV Lines
Optical
10x Optical Zoom
(F=3.8 to 38mm) Lens
Digital 10x (100x with optical)
Day & Night (ICR) Auto/ Day/ Night
Min. Shooting Distance 0.35m(W ide)/0.8m(Tele)
Digital Slow Shutter 2/4/8/16/24/32/64/128/ OFF
Normal
mode
0.7Lux (50IRE)
Min.
illumination Night
mode
0.02Lux (ICR On)
Lum inance S/N Ratio More than 50dB
Video Output VBS:1.0Vp-p/75 Ohm
CAMERA
MODULE
BLC ON / OFF
SPECIFICATIONS
