TP 400-5032-1-AT-N
Manual No. 7063141 ELECTRIC LIFT KIT (UTILITY VEHICLE)
5
Part No Description Item Qty Note
1 7063141 1 LINEAR ACTUATOR, Dump Bed Was 72641
2 7091821 2 SCREW, 1/2-13 x 3” Hex Head Cap
3 7091922 2 NUT, 1/2-13 Hex Nyloc
4 7035700 1 SWITCH, Deck Lift, Self Centering
5 7072687 1 DECAL, Bed Lift
6 7035702 1 SEAL, Switch
-- 7073812 1 INSTRUCTION SHEET, Bed Lift Kit
