Appendix A: J1–J6 Connector Pinouts
A
J1–J6 Connector Pinouts
The pinouts for connectors J1 through J6 of the 640-pin Adapter and the Daughterboard
are listed in
. Do not use pins that are labeled RESERVED.
Table 2: Pinouts for Connectors J1-J6
Connector
Pin
Signal
J1
A1
SEAT1
J1
A2
DUT171
J1
A3
DUT173
J1
A4
DUT170
J1
A5
DUT169
J1
A6
DUT168
J1
A7
DUT167
J1
A8
DUT166
J1
A9
DUT165
J1
A10
DUT164
J1
A11
DUT163
J1
A12
DUT162
J1
A13
DUT161
J1
A14
NC
J1
A15
TRIGGER
