4
ELECTRICAL SPECIFICATIONS:
Imager: 1/3" Format, Interline Transfer CCD
Video Output: 1.0 V p-p, 75 ohms.
White Balance: Auto-sensing
Synchronization: Line Lock
Model Horizontal Resolution Min Scene Illumination Back Light Compensation S/N
VSE-P6361xxxA Series 520 TVL 1.0 Lux @ F1.2 Center Zone >50 dB
VSE-P6362xxxA Series 520 TVL 1.0 Lux @ F1.2 Center Zone >50 dB
VSE-P6361xxxMA Series 520 TVL 1.0 Lux @ F1.2 Center Zone >50 dB
VSE-P6362xxxMA Series 520 TVL 1.0 Lux @ F1.2 Center Zone >50 dB
Model Type Range Aperture
VSE-P6361xxxA Series DC Auto Iris 2.8 to 12.0 mm F1.4 ~ 360
VSE-P6362xxxA Series DC Auto Iris 5.0 to 50 mm F1.4 ~ 185
VSE-P6361xxxMA Series Manual Iris 2.8 to 12.0 mm F1.4 ~ Close
VSE-P6362xxxMA Series Manual Iris 5.0 to 50 mm F1.4 ~ Close
Model Voltage Power
VSE-P6361xxxA Series 24 V AC, 60 Hz or 12 V DC 4.0 W
VSE-P6362xxxA Series 24 V AC, 60 Hz or 12 V DC 4.0 W
VSE-P6361xxxMA Series 24 V AC, 60 Hz or 12 V DC 4.0 W
VSE-P6362xxxMA Series 24 V AC, 60 Hz or 12 V DC 4.0 W
H ORIZONTAL R ESOLUTION , M INIMUM S CENE I LLUMINATION , BLC, AND S/N:
L ENS T YPE , R ANGE , AND A PERTURE :
V OLTAGE AND P OWER R ATINGS :
MECHANICAL SPECIFICATIONS:
Window: Lightly tinted acrylic.
Camera Mounting: A two-arm camera support bracket,
adjustable forward and backward, is included with each unit.
Construction: Housing is constructed of aluminum. The
lower domed window has a silk-screened window with a
lightly tinted viewing area.
Weight (approx.):
VSE-P6361xxxA Series: 3.8 lbs. (1.7 kg)
VSE-P6362xxxA Series: 3.8 lbs. (1.7 kg)
VSE-P6361xxxMA Series: 3.8 lbs. (1.7 kg)
VSE-P6362xxxMA Series: 3.8 lbs. (1.7 kg)
ELECTROMAGNETIC COMPATIBILITY:
EMC Requirements: FCC Class A
Safety: UL, cUL, CE.
