Connections and operating controls
1
3
Connections and operating controls
Delivery includes:
! AudioBeam
! 3 mains cables with plugs
! Interchangeable thread
5
/
8
"
to
3
/
8
"
! Instruction manual
! Document of warranty
³
LED operation indicator: green: AudioBeam is operational (standby)
red:
AudioBeam is not operational
·
Sensitivity selector switch (+6 dBm, –14 dBm)
»
On/off switch for distance sensor
(it is vital to observe the warning on page 15!)
¿
XLR-3 socket for audio input
INPUT
´ OVERLOAD
LED
²
BNC socket for modulator signal output
OUTPUT
¶
5
/
8
"
thread with adapter to
3
/
8
"
thread
º
IEC mains socket
¾
Air vents
µ
Steel clamp for securing the mains cable
INPUT
OUTPUT
OVERLOAD
