7 TP 400-2439-00-AT-SMA
Turbo Clean Sweep Twin Catcher - Adapter, Blade & Tube Group
1 1669193 1 SUPPORT
2 1921210 3 CAPSCREW, Hex Head, 3/8-16 x 1
3 1916965 3 LOCKWASHER, 3/8
4 1916950 3 NUT, Hex, 3/8-16
5 1930641 1 NUT, Hex Flange Lock, 1/4-20
6 1960252 1 CARRIAGE BOLT, 1/4-20 x 5/8
7 1705111 1 TUBE ASSEMBLY, Lower (Inc. Ref. Nos. 8, 9, & 14)
8 1705063 1 CLIP, Spring
9 910542 2 RIVET
10 1930531 2 SCREW, Truss Head, #10-32 x 1/2
11 1910531 4 WASHER, #10
12 1928919 2 NUT, Hex, Washer Assembly, #10-32
13 1704283 1 TUBE, Upper
14 1910531 2 WASHER
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691793 Turbo Clean Sweep Twin Catcher
