18_Installation & maintenance Installation & maintenance _19
installation & maintenance
ASSEMBLING THE RAT PROTECTION PANEL
1. It is easier engaging the shutter when
the set is lifted up a little, as shown in the
figure below.
2. Insert the shutter completely through the
engagement hole from the back.
HOW TO CONNECT THE DRAIN HOSE
IN CASE OF PUMP-DRAINED WASHER
• Attach the drain hose to the rear of the washer.
Install the clamp on the drain hose and tighten to prevent
leakage of water.
• Install the drain hose in the position of about 90~100cm
above the ground.
90~100cm
